Type | RXRB-01 Ready Board |
Structure | Protection |
Certification | ISO9001:2000, CE |
Form | All- packaged type |
Operation Voltage | YES |
Box Material | Low Voltage |
Shell Material | Plastic |
Shell Protection Grade | IP55 |
Availability: | |
---|---|
Quantity: | |
RXRB-01
RAIXIN
A Ready Board is a small gadget used to distribute power in a small building of two rooms or less.Since no wiring is needed, extension cables are used to supply power from the gadget to places where power is needed.When using Ready Board, one does not need electrical wiring in the property, therefore can save wiring cost.
Ready Board is basically a set of the following items:
Main Switch: for switching power supply on or off.
Circuit Breaker:for disconnecting supply in the event of a short circuit.
Earth Leakage System: for safety in case of leakages.One large lamp for lighting the room where Ready Board is installed
Three Switch Socket:Left Hand Side Switch Socket: For connecting extension cable to heavy power appliances such as cookers.
Middle Switch Socket:For connecting extension cable to medium power appliances such as a iron
Right Hand Side Switch Socket: For connecting extension cable to light power appliances such as radio, TV set, fans etc.
Ready Board is supplied to customers along with a metering unit for measuring electricity consumption.
Altitude (above sea level) :1600m
Maximum outdoor temperature: 40oC
Minimum outdoor temperature : 10oC
Maximum monthly mean temperature:35oC
Annual mean temperature:22oC
Maximum relative humidity:60% to 96%
In the place without risk of fire, explosion, severe vibration, serious pollution, chemical corrosion, without corrosive gas, dust, salt fog and dew in the air.
Name | READY BOARD-SMALL POWER DISTRIBUTION UNIT (SPDU) | |
Type | RXRB-01 | |
Standards | IEC60050, lEC60898-1, IEC61009-1,IEC 600309 Grupo C, C2a | |
Rated VoltageFrequency | 220/230V 50/60Hz | |
Earth leakage Circuit Breaker | TYPE:DZ47LE-63 1piece, 2-pole, 63A With overcurrent protection device | CCC,CE certificated Fire Resistance PA66 shell |
MCB | TYPE:DZ47-63 3 pieces, 1-pole, 1*25A.1-pole, 2*20A | |
Terminal | With Separate PE and N bar | |
3 Socket Outlets with Switch | 13A | |
Enclosure Material | Anti-flaming ABS or PC (Polycarbonate) | |
Degree of Protection | Anti-flaming ABS or PC (Polycarbonate) | |
Anti Vandal Bulkhead LUMINAIRE Fitting | ||
Light bulb | Replaceable 100W Max | |
Holder | B-22/E-27 | |
Main Supply | 220/230V, 50/60Hz | |
Finish | Black/ transparent | |
Weather rating | IP65 | |
Enclosure Material | PC cover, Nylon base | |
Lamp holder | With a bayonet lamp holder complies with IEC 61184 | |
Ambient | Suitable for indoor or outdoor use |
Check Before Mounting
The ready board is tested as qualified for delivery. Before the operation, please make sure that the package, ready board and the sealing screws on the enclosure of the ready board is intact. If there is any damage or the ready board is stored for a long time, the ready board should be rechecked by the authorized department before the installation and operation.
Before put into use, check the rated current and voltage of each element of ready board carefully, to see if it is the same as the fact, and carry on trial run with the switch closing and open method possessed by mechanism to check whether each index is suitable.
The ready board should be installed in dry and ventilated place where is firm and without stake.
In the course of mounting and using, strictly prohibit striking shell of ready board by hard object.
Users should not exchange the electrical elements which aren't the original model used.
Operation persons should learn about the structure, features, knowledge of installation, adjustment and maintaining of the ready board. Keep a record for the problem which my occur during using. Notify the manufacturer if necessary.
The ready board should be wired strictly in the right connection method. The fix up bolt and the screw down joint board should be tightened.
The ready board shouldn't be struck violently when it is being transport, opening packing. The box should be marked on "up" "take care" "avoid wet" etc.
Place it in a dry room when encasing, opening and keeping the package. Check whether the products and every component are complete.
The ready board should be stored in the original box within environmental temperature of -5℃-+45℃ and relative humidity not more than 85% and without corrosive gas.
The ready board should be kept in a dry, ventilation, damp-proof, quake-proof, harmful-gas-corrosive-proof storehouse, and it should be put on the shelves, not more than five cases . should be in the original packing condition in inner boxes. If keeping for a long period, please make sure that the environment is suitable.
Within 18 months since the delivery date, if it's found that the product doesn’t conform to the standards, it would be repaired or replaced free of charge on the condition that the customers operate it in the right way and no external caused damage on it and the seal is intact
