Consumer Unit

Distribution consumer unit, 4-24way, adjustable DIN rail for flush mount products, surface Mounted

Availability:

Quantity:



Inquire Add to Basket

Model:
RXCU
Brand:
RAIXIN-EM

Product Description

RXCU Series Distribution Box is suitable for residences,apartments, villas, hotels, commercial builidings and other places. Used in conjunction with Aoasis modular low-voltage power distribution products, it provides real estate developers, electrical switchgear manufacturers, and end users with a safe, stable and complete indoor low-voltage terminal power distribution solution.

OEM and ODM are welcome.

Technical Parameters

Rated Working Voltage	220~400VAC
Max.Rated Working Current	100A
Case Colour	Ivory:RAL9010
Housing Characteristics	Made of high quality cold-rolled steel plate and treated with electrostatic spray,it has excellent corrosion resistance.
Housing Characteristics	Independent grounding,ensure more safe and reliable grounding continuity,prevent electrical fire accidents.
Installation and Wiring	There are knockout holes at the inlet and outlet ends of the box body and the bottom of box for easy installation.
Installation and Wiring	There is enough installation space in the box body to meet the needs of user wiring.
Standard	BS 7671、GB/T 17466.1, GB/T 17466.24
Protection Grade	IP30
